Semi Battery Test Cell
Semi-Battery Cell Use for the electrochemical behavior research and analysis of plate electrodes, ion exchange membranes and membrane electrodes,high current, high reaction (generated) amount, strong corrosion resistance, gas-liquid phase separation
Description & Specification
| Semi-Battery Cell | |
| Model | Model:SEB072 |
| Specification | Main part: PTFE+Stainless steel
Capacity: 20ml Gas channel (graphite plate): 15mm * 15mm Working electrode: user prepare it, effectively control reaction area (1cm2) Counter electrode: carbon paper, carbon cloth or other material which with good conductivity (provided by user) |
| Feature | Mainly used for the electrochemical behavior research and analysis of plate electrodes, ion exchange membranes and membrane electrodes,high current, high reaction (generated) amount, strong corrosion resistance, gas-liquid phase separation.
Accurately locate the micro distance between the tip of the Luggin capillary and the working electrode. Suitable for gas-liquid reaction systems such as fuel cells, carbon dioxide reduction, water decomposition, nitrogen reduction, and zinc air batteries. |
